Secure Tauri/Windows Code Signing with Certum HSM

May 7, 2024 • Robert Olejnik

4 min to read

While doing releases with Tauri is pretty straightforward and well-documented, the Code Signing for MacOS is spot-on, but the Windows Code Signing is not that straightforward. Tauri documentation assumes you have a certificate file (pfx - with certificate & key) - but most (if not all) Code Signing Certificates are sold on dedicated HSMs (Hardware Security Modules) that must be FIPS 140-2 compliant.

Thus to handle signing:

One has to have a self-hosted GitLab/Github Runner - which just physically can have the HSM connected to the USB (and of course the runner needs to be in a secure network location and well as the system needs to be secured).
There needs to be a solution & tools to handle this process automatically during the build & release.

Most certificate authorities have a dedicated solution for that (DigiCert, Sectigo) or solutions, examples, and a great documentation (SSL.com) but we have chosen Certum Code Signing certificate for two reasons, they operate as us in Szczecin Poland and they have a great Open Source Code Signing product - and defguard is an open-source project. The downside is that they do not have any CI/CD documentation or solutions, and weirdly (everything should be on the internet, right?) there are no docs, solutions, snippets, projects, or blogs (you name it), that could help us set up this process.

So after weeks of going back and forward with the Certum support and going nowhere (greeting for our colleagues), we took this project on our shoulders - and here are the recipes for building a Debian GNU/Linux CI/CD runner.

We assume you have:

a configured GitHub/GitLab self-hosted runner based on Debian GNU/Linux (but Ubuntu should work as well)
Bought an Open Source Code Signing Certificate set from Certum
Have the certificate issued and the key is on the HSM shipped by Certum and it’s connected to the runner.
You also have downloaded the certificate file in PEM format (from certum website), and placed it in /srv/codesign/certum/certificate.pem

Now we need to prepare the runner system to support the HSM. First let’s install all necessary system software:

apt install opensc opensc-pkcs11 libpcsclite-dev pcscd libacsccid1 \
    libengine-pkcs11-openssl osslsigncode

Now, we need to install the Linux version of proCertumCardManager provided by Certum:

mkdir /srv/codesign/
cd /srv/codesign/

# We download proCertumCardManager
wget https://www.files.certum.eu/software/proCertumCardManager/Linux-Ubuntu/2.2.11/proCertumCardManager-2.2.11-x86_64-ubuntu.bin

# We do not install the software, just extract it
/srv/codesign/proCertumCardManager-2.2.11-x86_64-ubuntu.bin --keep
mv dist certum

# create links, if you would like to actually use the
# Certum Card Manager software

ln -s /srv/codesign/certum/cryptoCertum3PKCS-3.0.6.69-MS.so /usr/lib/libcrypto3PKCS.so
ln -s /srv/codesign/certum/cryptoCertum3PKCS-3.0.6.69-MS.so /usr/lib/libcryptoCertum3PKCS.so

Now, we can check if the system sees the HSM and can show us the certificate & key details:

$ pkcs11-tool --module /srv/codesign/certum/sc30pkcs11-3.0.6.68-MS.so --login --list-objects

Using slot 0 with a present token (0x1)
Logging in to "profil standardowy".

# here you need to provide the PIN to access the card/HSM

Please enter User PIN:

# After providing the PIN, you should see the contents of the card

Private Key Object; RSA
  label:      Open Source Developer, Robert Olejnik
  ID:         352c322687efb09df068a792c49cbac631d40cf0
  Usage:      decrypt, sign, unwrap
warning: PKCS11 function C_GetAttributeValue(ALWAYS_AUTHENTICATE) failed: rv = CKR_ATTRIBUTE_TYPE_INVALID (0x12)

  Access:     sensitive, always sensitive, never extractable, local
Public Key Object; RSA 4096 bits
  label:      Open Source Developer, Robert Olejnik
  ID:         352c322687efb09df068a792c49cbac631d40cf0
  Usage:      encrypt, verify, wrap
  Access:     local
Certificate Object; type = X.509 cert
  label:      Open Source Developer, Robert Olejnik
  subject:    DN: C=PL, ST=zachodniopomorskie, L=Szczecin, O=Open Source Developer, CN=Open Source Developer, Robert Olejnik
  serial:     29EE7778CA5217107841BBBF6B3062E1
  ID:         352c322687efb09df068a792c49cbac631d40cf0

! As you can see, the key ID (this is important) is: 352c322687efb09df068a792c49cbac631d40cf0

Now the final, let’s check if the code signing works - for that we have a defguard.exe unsigned binary, which we will sign and check if it works:

$ osslsigncode sign \
  -pkcs11module /srv/codesign/certum/sc30pkcs11-3.0.6.68-MS.so \
  -certs /srv/codesign/certificate.pem \
  -key 352c322687efb09df068a792c49cbac631d40cf0 \
  -pass <PIN> \
  -h sha256 \
  -t http://time.certum.pl/ \
  -in defguard.exe \
  -out defguard-signed.exe


# You should see the following message and result:

Engine "pkcs11" set.
Succeeded

And checking the signature:

$ osslsigncode verify defguard-signed.exe

Current PE checksum   : 0134E4A0
Calculated PE checksum: 0134E4A0

Signature Index: 0  (Primary Signature)
Message digest algorithm  : SHA256
Current message digest    : 13A86CCDF9DE5177ACC15A3AC895A1F39A652D85F6E9C3533C151D64547F930A
Calculated message digest : 13A86CCDF9DE5177ACC15A3AC895A1F39A652D85F6E9C3533C151D64547F930A

Signer's certificate:
    Signer #0:
        Subject: /C=PL/ST=zachodniopomorskie/L=Szczecin/O=Open Source Developer/CN=Open Source Developer, Robert Olejnik
        Issuer : /C=PL/O=Asseco Data Systems S.A./CN=Certum Code Signing 2021 CA
        Serial : 29EE7778CA5217107841BBBF6B3062E1
        Certificate expiration date:
            notBefore : Mar 21 06:12:37 2024 GMT
            notAfter : Mar 21 06:12:36 2025 GMT

Number of certificates: 4
    Signer #0:
        Subject: /C=PL/ST=zachodniopomorskie/L=Szczecin/O=Open Source Developer/CN=Open Source Developer, Robert Olejnik
        Issuer : /C=PL/O=Asseco Data Systems S.A./CN=Certum Code Signing 2021 CA
        Serial : 29EE7778CA5217107841BBBF6B3062E1
        Certificate expiration date:
            notBefore : Mar 21 06:12:37 2024 GMT
            notAfter : Mar 21 06:12:36 2025 GMT
# And so on...
# And so on...
# And so on...

Now what is left for you to do, is add the osslsigncode sign to your pipeline, and don’t forget to make the PIN a secret.

Robert Olejnik - Founder, Security and Open Source Advocate
